Bucher Vaslin Flavy FGC
Bucher Vaslin Flavy FGC
Crossflow Wine Filtration System
The Flavy FGC is Bucher Vaslins most advanced tangential flow filtration system, purpose-built for wineries demanding energy efficiency, reliability, and respect for wine quality.
Backed by Eco-Energy technology, it reduces electricity consumption by up to 95% while delivering exceptional productivity and consistent results. Designed with operators in mind, the FGC combines silent operation, intuitive controls, and Industry 4.0 connectivity, making it the benchmark for large-scale wineries across Australia.
Bucher Vaslin equipment is made to order, contact our sales team via the enquire button below.
- Family owned and operated
- 50 years local experience
- Secure checkout
Specifications
Specifications
FGC 1
Flow rate range for white and rosé wines: 50–80 hl/h
Flow rate range for red wines: 25–50 hl/h
Flow rate range for in-line bentonite injection: 25–35 hl/h
Total power: 30 kW
Length: 2800 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 6.5 m²
Tare weight: 1600 kg
Water weight: 1900 kg
FGC 2
Flow rate range for white and rosé wines: 100–160 hl/h
Flow rate range for red wines: 50–100 hl/h
Flow rate range for in-line bentonite injection: 50–70 hl/h
Total power: 40 kW
Length: 3600 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 8.2 m²
Tare weight: 2100 kg
Water weight: 2700 kg
FGC 3
Flow rate range for white and rosé wines: 150–240 hl/h
Flow rate range for red wines: 75–150 hl/h
Flow rate range for in-line bentonite injection: 75–105 hl/h
Total power: 50 kW
Length: 4400 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 10.7 m²
Tare weight: 2700 kg
Water weight: 3500 kg
FGC 4
Flow rate range for white and rosé wines: 200–320 hl/h
Flow rate range for red wines: 100–200 hl/h
Flow rate range for in-line bentonite injection: 100–140 hl/h
Total power: 60 kW
Length: 5200 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 12.6 m²
Tare weight: 3300 kg
Water weight: 4300 kg
Flow rates measured for wines with turbidity < 100 NTU and tank volume = 500 hl - Non-contractual values, depending on the profile of the wine and for pipes of diameter 80 - A smaller diameter pipe will reduce filtration flow rates.
Flow rate range for white and rosé wines: 50–80 hl/h
Flow rate range for red wines: 25–50 hl/h
Flow rate range for in-line bentonite injection: 25–35 hl/h
Total power: 30 kW
Length: 2800 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 6.5 m²
Tare weight: 1600 kg
Water weight: 1900 kg
FGC 2
Flow rate range for white and rosé wines: 100–160 hl/h
Flow rate range for red wines: 50–100 hl/h
Flow rate range for in-line bentonite injection: 50–70 hl/h
Total power: 40 kW
Length: 3600 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 8.2 m²
Tare weight: 2100 kg
Water weight: 2700 kg
FGC 3
Flow rate range for white and rosé wines: 150–240 hl/h
Flow rate range for red wines: 75–150 hl/h
Flow rate range for in-line bentonite injection: 75–105 hl/h
Total power: 50 kW
Length: 4400 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 10.7 m²
Tare weight: 2700 kg
Water weight: 3500 kg
FGC 4
Flow rate range for white and rosé wines: 200–320 hl/h
Flow rate range for red wines: 100–200 hl/h
Flow rate range for in-line bentonite injection: 100–140 hl/h
Total power: 60 kW
Length: 5200 mm
Width: 2440 mm
Height: 2510 mm
Floor area: 12.6 m²
Tare weight: 3300 kg
Water weight: 4300 kg
Flow rates measured for wines with turbidity < 100 NTU and tank volume = 500 hl - Non-contractual values, depending on the profile of the wine and for pipes of diameter 80 - A smaller diameter pipe will reduce filtration flow rates.
Features
Features
Eco-Energy patented process – cuts power use by up to 95%
High productivity with stable filtration rates
Reduced waste volumes and lower running costs
Industry 4.0 ready – remote monitoring via Winect app
Simple, quiet, and safe operation
Injection system for up to 3 oenological products at inlet and 3 at outlet
Options for bentonite injection, turbidimeter, conductivity probe, nitrogen injection
Designed for filtration of white, rosé, and red wines, including sparkling
High productivity with stable filtration rates
Reduced waste volumes and lower running costs
Industry 4.0 ready – remote monitoring via Winect app
Simple, quiet, and safe operation
Injection system for up to 3 oenological products at inlet and 3 at outlet
Options for bentonite injection, turbidimeter, conductivity probe, nitrogen injection
Designed for filtration of white, rosé, and red wines, including sparkling
